After downloading the official ONNX model, I got a 400-byte XML error file saying I downloaded a fake model

Hello, I encountered a model download issue while following the emotion example in SpacemiT’s official model-zoo-vision repository, and I’d like to ask for help.

Repository URL:

Relevant directories:

examples/emotion
applications/emotion_detection

According to the configuration file, the emotion example requires the model at:

~/.cache/models/vision/emotion/emotion_resnet50_final.q.onnx

In addition, applications/emotion_detection uses:

~/.cache/models/vision/emotion/emotion_resnet50_features.dynq.onnx
~/.cache/models/vision/emotion/emotion_lstm_affwild2_final.q.onnx

However, after running the official download script, I received XML error files of just over 400 bytes instead of ONNX models. Here’s what I found:

emotion_resnet50_final.q.onnx: 443 bytes, XML 1.0 document
emotion_resnet50_features.dynq.onnx: 449 bytes, XML 1.0 document
emotion_lstm_affwild2_final.q.onnx: 448 bytes, XML 1.0 document

The files contain:

NoSuchKey
The specified key does not exist.

The corresponding download URLs are:

https://archive.spacemit.com/spacemit-ai/model_zoo/vision/emotion/emotion_resnet50_final.q.onnx

https://archive.spacemit.com/spacemit-ai/model_zoo/vision/emotion/emotion_resnet50_features.dynq.onnx

https://archive.spacemit.com/spacemit-ai/model_zoo/vision/emotion/emotion_lstm_affwild2_final.q.onnx

Have these model files been moved to a new download location? Could you provide working download URLs or recommend emotion model files for the current version?

I’d also like to confirm a few configuration details:

  1. Is the class order in assets/labels/emotion.txt still:
    neutral, happiness, sadness, surprise, fear, disgust, anger
  2. Is the configuration in examples/emotion/config/emotion.yaml still compatible with the current model?
  3. Does enabling SpaceMITExecutionProvider on the K1 require any additional environment variables or shared library path configuration?
  4. If libonnxruntime.so cannot be found at runtime, what is the recommended way to set LD_LIBRARY_PATH?

Thank you.
:~/model-zoo-vision$ cd ~/model-zoo-vision

rm -rf ~/.cache/models/vision/emotion_test
mkdir -p ~/.cache/models/vision/emotion_test

cd ~/.cache/models/vision/emotion_test

echo “下载 static emotion model…”
curl -L -o emotion_resnet50_final.q.onnx
https://archive.spacemit.com/spacemit-ai/model_zoo/vision/emotion/emotion_resnet50_final.q.onnx

echo “下载 feature model…”
doneho -c 120 “$f”====“节:”/spacemit-ai/model_zoo/vision/emotion/emotion_ls
Downloading static emotion model…
% Total % Received % Xferd Average Speed Time Time Time Current
Dload Upload Total Spent Left Speed
0 0 0 0 0 0 0 0 --:–:-- --:–:-- --:–:-- 0 0 0 0 0 0 0 0 --:–:-- --:–:-- --:–:-- 100 443 100 443 0 0 778 0 --:–:-- --:–:-- --:–:-- 778
Downloading feature model…
% Total % Received % Xferd Average Speed Time Time Time Current
Dload Upload Total Spent Left Speed
0 0 0 0 0 0 0 0 --:–:-- --:–:-- --:–:-- 100 449 100 449 0 0 886 0 --:–:-- --:–:-- --:–:-- 8100 449 100 449 0 0 885 0 --:–:-- --:–:-- --:–:-- 885
Downloading LSTM model…
% Total % Received % Xferd Average Speed Time Time Time Current
Dload Upload Total Spent Left Speed
0 0 0 0 0 0 0 0 --:–:-- --:–:-- --:–:-- 100 448 100 448 0 0 813 0 --:–:-- --:–:-- --:–:-- 816
Check results:
total 12K
-rw-rw-r-- 1 bianbu1 bianbu1 448 Jun 11 17:03 emotion_lstm_affwild2_final.q.onnx
-rw-rw-r-- 1 bianbu1 bianbu1 449 Jun 11 17:03 emotion_resnet50_features.dynq.onnx
-rw-rw-r-- 1 bianbu1 bianbu1 443 Jun 11 17:03 emotion_resnet50_final.q.onnx
emotion_lstm_affwild2_final.q.onnx: XML 1.0 document, ASCII text
emotion_resnet50_features.dynq.onnx: XML 1.0 document, ASCII text
emotion_resnet50_final.q.onnx: XML 1.0 document, ASCII text

First 120 bytes of each file:
===== emotion_lstm_affwild2_final.q.onnx =====

<?xml version="1.0" encoding="UTF-8"?> NoSuchKey The specified key does not exist. NoSuchKey The specified key does not exist. NoSuchKey The specified key does not exist.</Me bianbu1@k1:~/.cache/models/vision/emotion_test$ rm -rf ~/.cache/models/vision/emotion_test rm -f ~/.cache/models/vision/emotion/*.onnx bianbu1@k1:~/.cache/models/vision/emotion_test$ cd /home/bianbu1

pkill -f optimized_camera
pkill -f decision_engine.py
pkill -f web_preview.py
pkill -f screen_interaction.py
pkill -f emotion_ai_worker.py
pkill -f aplay

/home/bianbu1/start_warm_station_all.sh
sleep 10

cat /home/bianbu1/camera_status.json
ps -o pid,pcpu,pmem,cmd -C python3us | head -c 500
Stopping old programs…
Starting camera recognition program…
Starting decision management program…
Enhanced state analysis program is temporarily disabled
Starting small-screen interaction program…
Starting web preview program…

Warm Heart Station multimodal recognition system started
Open in a browser on your computer:
http://10.34.218.232:8080

View camera log: tail -f /home/bianbu1/camera.log
View enhanced analysis log: tail -f /home/bianbu1/enhanced.log
View web log: tail -f /home/bianbu1/web.log
{
“user_present”: true,
“emotion”: “NEUTRAL”,
“confidence”: 0.93,
“probabilities”: {
“HAPPY”: 0.07,
“NEUTRAL”: 0.93,
“STANDBY”: 0.0
},
“face_box”: {
“x”: 140,
“y”: 14,
“w”: 150,
“h”: 150
},
“time”: “2026-06-11 17:05:10”
}{“user_present”: true, “emotion”: “NEUTRAL”, “confidence”: 0.93, “probabilities”: {“HAPPY”: 0.07, “NEUTRAL”: 0.93, “STANDBY”: 0.0}, “face_box”: {“x”: 140, “y”: 14, “w”: 150, “h”: 150}, “time”: “2026-06-11 17:05:11”, “last_action”: “”, “chat_reply”: “The current state is relatively calm. You can ask the user if they need help.”, “chat_state”: “Rule-based emotion Q&A connected”, “raw_emotion”: “NEUTRAL”, “display_probabilities”: {“HAPPY”: 0.07, “NEUTRAL”: 0.93, “STANDBY”: 0.0}, “current_frame_probabilities”: {"HA
PID %CPU %MEM CMD
32068 40.3 1.7 python3 optimized_camera_working.py
32070 1.6 0.1 python3 -u decision_engine.py
32072 69.5 3.6 python3 -u screen_interaction.py
32073 4.7 0.2 python3 web_preview.py
I want to integrate the modei-zoo model into my board.

你再执行下,现在模型可以下载了,之前没推到外网。
1.标签顺序是这样的。
2.适用。
3,4. 不需要,按文档安装环境即可,只需要注意k1的推理线程只有4个。
k1 跑模型注意手动给普通用户/dev/tcm权限。
